Custom Aperture rig

A few years ago, I found myself getting very interested in bokeh.  Specifically, how the aperture shape in an otherwise well-corrected lens will give shape and structure to the blur field in an image.
original_bokeh_104
(This was long before LensBabies came along.)

So I decided to create a lens mount that would let me drop in different aperture plates.  Since most 35mm lenses are monolithic (breaking them open to change the aperture would be a big project), I cut a large format mount and rented some 4x5 optics.  In place of the shutter (my 35mm camera has a focal plane shutter), I milled a slot for aperture plates.

original_bokeh_95original_bokeh_101

Here are some samples of the result.  I liked the more abstract versions from our test shoot, but the blur fields would easily make an interesting, weighty background for traditional cinematography, too.

original_bokeh_103original_bokeh_48

Also, this could theoretically be done in software if you have a light-field image; coarsely, this can be done with Lytro's camera system, though this is one area where analog has higher resolution than digital at the moment.
